Application
It is a kind of multi-functional machine integrated with slitting and rewinding. It mainly slits large-sized or big roller stretch film into small ones, which avoids the split-level film and improves the technical index of product, such as level and appearance quality etc.
It mainly is used to re-wind the PE stretch film and PE cling film. The automatic rewinder can greatly improve the work efficiency
Feature
1.This fresh keeping film rewinding and slitter machine is a kind of multi functional machine intergrated with slitting and rewinding.
2.It mainly slits large sized stretch film into small ones which avoids the split level film and improves the technical index of products, such as level and appearance quality etc.
3.It also has general film can fit for this machine.
Main specification
| Modle |
HTW-500 |
| Operation way |
PLC computer controlled |
| Width of finished products |
500mm |
| Main motor |
6kw |
| Linear speed of machinery |
200-800m/min |
| Rewind type |
Full automatic |
| Diameter of parent roll(max) |
400mm(Diameter) |
| Width of parentroll(max) |
550mm |
| Diameter of sub-roll(max) |
80(Diameter) |
| Core specification of sub-roll |
inner37.5mm outer41.5mm |
| Overall dimensions(L*W*H) |
1.6m*1.1m*1.1m |
| Weight |
1200kg |
